Potter AFC-100 Analog/Addressable Releasing Fire Alarm Control Panel, 100 Addresses
AFC-100
|PL-AFC100
Shop all Potter Electric Signal, LLC
Potter AFC-100 Analog/Addressable Releasing Fire Alarm Control Panel, 100 Addresses
AFC-100 | PL-AFC100
Please sign in to view pricing, availability, and to add to cart.
Overview
Specifications
Documents
Product Overview
The AFC-100 is an analog-addressable fire alarm system with a total system capacity of 100 addresses. Additional capacity on the system is achieved using multi-point SLC modules. The control panel utilizes the exclusive Potter protocol that includes a complete line of sensors and modules. Each SLC may be comprised of any combination of smoke sensor, heat detectors or modules and allows for a total of 50 Ohms of impedance and may use any wire compliant with the National Electrical Code (NEC).
Main Features
- 100-Addresses available on this analog addressable system
- Additional system capacity achieved via multi-point SLC modules
- 99-Software zones
- NFPA 72 Compliant Smoke Sensitivity Test built-in
- System Operates as Class A or Class B for SLC, P-Link and NACs
- 5A Power supply, expandable to 310A
- 2 NACS, regulated, rated at 3A each, expandable to 188
- 2 Input / Output (I/O) Circuits for system flexibility rated at 1A each
General Information
Name: Potter AFC-100 Analog/Addressable Releasing Fire Alarm Control Panel, 100 Addresses
Category: Potter Electric Signal, LLC, Fire, Fire Control Panels, Fire Alarm Control Panels
UPC Code: 785192024811
Country of Origin: United States. Country of origin is subject to change.
Specifications
ADI Part Number PL-AFC100 Brand Name Potter Electric Signal, LLC Manufacturer Potter Electric Signal, LLC Manufacturer Part Number AFC-100 Product Model AFC-100 Product Name Fire Alarm Control Panel Product Series AFC Product Type Fire Alarm Control Panel
Connectivity Technology Wired Number of Events Log 4000 Number of Standard Zones 99 Number of Zones Supported 100 Panel Control Type Addressable
Display Type LCD
Depth 3.9" Height 17" Width 16"
Input Voltage 120V AC, 230V AC
Limited Warranty 5-Year
Country of Origin US
